Irrigation Stainless Steel Single Bag Filter Housing Industrial Water Movable

Basic Information
Place of Origin: HENAN PROVINCE IN CHINA
Brand Name: YW
Certification: CE, ISO
Model Number: YWDL-6P2S
Minimum Order Quantity: 1
Price: USD+500-10000+set
Packaging Details: wooden case, net for container
Delivery Time: 5-8 work days
Payment Terms: T/T, L/C, D/A, Western Union, MoneyGram
Supply Ability: 600+set+per month
Detail Information
Product Name: Duplex Bag Filter Material: Ss304 Steel And 316L
Bag Qty: 12 Max Flow: 80t/h
Inlet/Outlet Dia: DN80mm Working Pressure: 0.1-0.6Mpa
Filter Housing Type: Stainless Steel Filter Housing Aftersale Service: Video Technical Support, Online Support
Appearance: Polished Finishing Application: Oil, Food,drinking Chemical Industry Etc
High Light:

irrigation filter housing

,

industrial water filter housing

,

industrial filter housing


Product Description

Stainless Steel Industrial Movable Filter Food Grade Single Bag Filter



Application





This equipment is all made of stainless steel SUS304/316L, and the inner and outer surfaces are polished. The filter cartridge is equipped with a stainless steel filter screen and a filter support basket; the top is equipped with a vent valve to discharge the air in the filter during filtration. The upper cover and the filter cartridge are connected with a quick-opening structure, which is more convenient to clean (replace) the filter screen. Three adjustable feet make the filter stable on the ground. The connecting pipeline adopts live connection or clamp connection, and the inlet and outlet valves are opened and closed by three-way ball valves, which are pressure-resistant and temperature-resistant, flexible and convenient to operate, and no liquid leakage is more hygienic. The pipe joint adopts expansion connection. After 0.3Mpa water pressure test, the three-way external thread plug is flexible to open and close. The equipment has a compact structure, convenient operation and simple maintenance. In addition: Two single-tube filters can be assembled on a machine base, and there is no need to stop when cleaning the filter to ensure its continuous operation. It is the first choice for non-stop production line filter devices.



Specification



Models No. of filter bags Filtration Area(m2) Flow rate (m³/h) I/O Connections Max pressure (Mpa) Housing Diameter(mm) Total Height(mm) Housing Height(mm)
DL-2P2S 2 1 70 DN50 0.5 456 1572 1144
DL-3P2S 3 1.5 105 DN80 0.5 508 1592 1190
DL-4P2S 4 2 140 DN100 0.5 558 1632 1244
DL-5P2S 5 2.5 175 DN150 0.5 608 1788 1254
DL-6P2S 6 3 210 DN150 0.5 658 1854 1300
DL-7P2S 7 3.5 215 DN150 0.5 710 1875 1340
DL-8P2S 8 4 280 DN150 0.5 760 1922 1404
DL-10P2S 10 5 350 DN200 0.5 910 2004 1430
DL-12P2S 12 6 420 DN200 0.5 962 2064 1460
DL-14P2S 14 7 490 DN200 0.5 1012 2124 1490
DL-16P2S 16 8 560 DN250 0.5 1112 2146 1512
DL-18P2S 18 9 630 DN250 0.5 1162 2225 1595
DL-20P2S 20 10 700 DN250 0.5 1212 2280 1640
DL-22P2S 22 11 770 DN250 0.5 1366 2320 1694
DL-24P2S 24 12 840 DN300 0.5 1416 2358 1748

Irrigation Stainless Steel Single Bag Filter Housing Industrial Water Movable 0
